Range of Products >>Telecommunication  >> Patch panel >> NP-09







  Product Name: Telecommunication Patch panel

P/N:  NP-12

Specification and data sheet:

1. Operation Temperature: -20 to 60, relative humidity:85%,Air pressure: 70-106Kpa
2. With Cat5e keystone modules used for 19 Inch cabinet, Complete metalation and reed construction, modularization design;
3. IDC: Phosphor bronze and gold plating (20-50u),suitable diameter 0.4-0.6mm,durability 200 cycles;
4. Contact Pin: phosphor bronze and gold plating (20-50u),mating durability not less than 750 cycles;
5. Anti-burn performance: plastic part made from PPO and PC or PBT and ABS, meeting the international standard;
6. Intermediate resistance: No more than 20m in normal atmosphere pressure (not including bulk resistor);
7. Insulated resistance: no less than 1000min normal atmosphere pressure.
8. The intensity of anti-currency: DC1000V(AC700V),no puncture and flash-over phenomenon in one mins. Accord with industry standard.
9. Backwave loss: >34dB(1<f<100MHz)
10. Minimum near end cross talk loss 100MHz:>43dB(100MHz);Minimum far end cross talk loss 100MHz:>35.3dB(100MHz)
11. Label: clear label to ensure easy to manage;
12. Type: unshielded
13. Standard: designed by international ISO/IEC11801 and TIA/EIA568
