Range of Products >>Terminal Block >> Spring & Lighting TB >>  GSL001S







Standard
UL
IEC
Rated voltage
300V
250V
Rated current
5A
15A
Wire range
20-18AWG
0.2-2.5mm2
Withstanding voltage
AC1250V/1Min
Ambient temperature
-40°C~+105°C
Strip length
9-10mm
Pitch
3.50/3.81/ 5.00 / 5.08mm(.100")
Poles
1P-XXP
Housing
PA66+5%GF.,UL94V-0
Pin header
Brass,Tin plated
Wire guard
Stainless steel



How to Order:

GSL001S

3.81

02 P

1


Series No.   Pitch (mm)   No.of Poles   Color

Customer Request

    3.50

1. Grey     2.Blue


    3.81

3. Black   4.Green


    5.00

5.Orange   6.Red


    5.08

7.Natural   8.White
